ECI Multi Functional Weighing Controller Operating Manual
Page 122
Relay2
Relay3
Relay4
Relay2, Relay3 and Relay 4 menus are same as Rela1 menu.
Inputs
It is the section on the relay module where the digital input settings are made.
Input1
The parameter that contains options related to the
input. The options are;
1) Inactive: No task is appointed for the input
signal
2) Zeroing: The device performs zeroing operation
when input signal is detected.
3) Tare: The device performs taring operation when input signal is detected.
Input2
Input3
Input4
Input 2, Input 3 and Input 4 are same as the Input 1 menu.
