12.2.1 Bag Filling:
The operation sequence for bag filling is as follows.
1) Start command is waited.
2) Bag Handling Output is activated.
3) Start-up Delay period is waited (if "Start-upDelay" period is entered)
4) Taring is made. (If Auto Taring is selected "On")
5) Quick Filling Output and Weighing in Progress output is activated.
6) The Quick Filling Output becomes passive depending on the quantity taken
7) Slow Filling Output is activated.(If the feeding is selected as "Quick+Slow")
8) Slow Filling Output and Weighing in Progress output is deactivated depending on the quantity taken.
9) Discharge Delay period is waited (if "DischargeDelay" period is entered)
10) Bag Handling Output is deactivated.
11) Discharge Output is activated.
12) When it reduced under the Zero Stripe, Operation Completed output is activated and the discharge output
is deactivated.
