4.1 Technical Specifications
Model
ECI, E Series
Load Cell Input
+/- 2.50–160mV/V
A/D Speed (/second)
1600
Screen Resolution
6 digit (1/1.000.000)
Supply
12-24V DC
Display
LCD (101x33 pixel graphic, 4.5 inch)
Communication Terminal (Standard)
RS-232 (9600-115200bps)
Communication Remote Display (Standard)
For Remote Display (Opto-Coupler)
Communication Option Module (Optional)
RS-232-RS-485 / RS-422 (E-MDL-COM insulated)
Load Cell Feeding
10 VDC (280mA, maximum 10 load cells)
Operating Temperature
-10C / +50C
Protection Class
IP65 (Front Panel)
(Standard: Supplied as standard hardware with the device)
(Optional: Inserted to the device as additional hardware)
