ECI Multi Functional Weighing Controller Operating Manual
Page 139
7.3.6.2 Optional EXP Module Menu
Following menus will appear if EXP module is inserted to slot 6.
EXP Module
Outputs
It is the menu where the Digital Output settings are made. Same as the relay module output menu.
Output1
.
Output16
Inputs
Same as the relay module input menu.
Input1
.
Input8
Service
Same as the relay service input menu.
Inputs
Outputs
