ECI Multi Functional Weighing Controller Operating Manual
Page 278
14.5.4 Writing to EEPROM section
Such that the Modbus ID:1, following data array is sent in order to change the Unit information at address no
47 (0x2F) on EEPROM as kilogram.
Modbus
ID
Function
Code
Start
Address
Register
Number
Numbe
r
d
Register
Reg A Reg B CRC Data
NOTE: As a matter of course, when a value is written to the EEPROM section, only the EEPROM
daat changes. There are two ways to update the RAM values with the EEPROM values;
1-) It is necessary to disconnect, then connect the power.
2-) 0x0A Command must be executed over Modbus. (0x0A: update parameters from EEPROM)
