ECI Multi Functional Weighing Controller Operating Manual
Page 109
Period
Selection for optional module serial out transmission frequency. The options are;
1) Stable: Transmission is made when stability is observed (10Hz).
2) 6/Min: Option for transmission frequency per minute.
3) 1/Sec: Option for transmission frequency per
second.
4) 10/Sec: Option for transmission frequency per
second.
5) 100/Sec: Option for transmission frequency per
second.
6) 400/Sec: Option for transmission frequency per
second.
7) 800/Sec: Option for transmission frequency per second.
Note: Period can be selected as only "Stable" when "Command" or "Stability" modes are selected.
When "Speed" Mode is selected, Period can be selected as 100-800/Sec
When "Accuracy" or "Detail" mode is selected, Period can be selected as 6/Min-10/Sec
No Period can be selected when "Off" mode is selected.
