11.2.1 Screen Layout
1) Recipe Name The name of the recipe selected is shown.
2) Total batching quantity request is shown
3) Number of the silo currently filled / total number of silo used in the recipe.
4) Filling speed indicator. Filling speed is indicated as two levels.
5) Current quantity of the material taken from the silo that is filled or the quantity of materials discharged during the
discharge.
6) Total quantity of the material filled.
7) The occupancy rate indicator of the weighing scale proportional to the target value. It shows the scale capacity
status as 5 levels.
8) Name of the silo filled.
9) The quantity calculated (to be filled) from the filled silo according to the recipe.
10) Filling (Batch) number / Total filling (Batch) number.
