ECI Multi Functional Weighing Controller Operating Manual

Page 23

• Slot1: Used for the Terminal (Supply & Communication) Module. Following module(s) can be used;

E-ECI-PWR (Standard) module can be inserted.

• Slot2: Used for Weighing (Load Cell) Module. Following module(s) can be used;

E-ECI-LC (Standard) module can be inserted.

• Slot3: Used for optional Communication Module. Following module(s) can be used;

E-MDL-COM (Optional), RS232 + RS485/RS422 Module

E-MDL-PRF (Optional), Profibus Module

E-MDL-EIP (Optional), Ethernet IP Module

• Slot4: Used for Optional Input/Output modules. Following module(s) can be used;

E-MDL-RLY, 4in/4out Module (Optional)

E-MDL-DAC, 0-10V / 4-20mA Analogue +2in/1out Module (Optional)

• Slot5: Used for Optional Input/Output modules. Following module(s) can be used;

E-MDL-RLY, 4in/4out Module (Optional)

E-MDL-DAC, 0-10V / 4-20mA Analogue +2in/1out Module (Optional)

• Slot6: Used for Expansion modules. Following module(s) can be used;

E-MDL-EXP, 8in/16out expansion module (Optional)

E-MDL-BCD, 20out/2In Optical Insulated BCD or Binary Output Module (Optional)
