ECI Multi Functional Weighing Controller Operating Manual
Page 272
16-31 (Y/O)
1
Recipe Formula Selected
32 (/O)
1
Batching Status
33 (/O)
1
Batching Operation Sequence
34 Y/O
2
Target Value
38 (Y/O)
1
User Data Area 1
39 (Y/O)
1
User Data Area 2
40 (Y/O)
1
User Data Area 3
41 (Y/O)
1
User Data Area 4
(Y/O) Writable and Readable
(/O) Read Only
14.4.3 Filling Program
Address
Word
Number
Function
0 (Y/O) 1
Command register: it is used for the special functions together with the Reg A and
Reg B.
1 (Y/O)
1
Reg A: General Purpose Data Register.
2 (Y/O)
1
Reg B: General Purpose Data Register.
5
1
Status A (Explanations are stated above in detail)
6
1
Status B (Explanations are stated above in detail)
