ECI Multi Functional Weighing Controller Operating Manual
Page 63
6) Printer: It is the printer connection option. This option is locked as it is not active under the
indication program.
Period
Selection for RS232 serial out sending frequency.
The options are;
1) 6/Min
2) 1/Sec
3) 10/Sec
4) 100/Sec
5) 400/Sec
6) 800/Sec
Not: Period menu is not shown when "Command" or "Stability" modes are selected.
When "Speed" Mode is selected, Period can be selected as 100-800/Sec
When "Accuracy" mode is selected, Period can be selected as 6/Min-10/Sec
When "Detail" mode is selected, Period can be selected as 6/Min-10/Sec
