Evolis Avansia - Page 192

Service Manual_AVA1_ENG-20220922_I 192
7. Retrieve the springs and the levers: see picture below.
8. Carry out steps 9-2 to 9-12 (page 130
).
9. At the back of the printer undo the cables from their holder Remove the screw from the fan carter.
10. Remove the screw from the fan carter. Gently disengage the carter. Put the different modules on
the left of the printer.
