Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 238
5. Insert 1mm thickness gauge under 2 red arrows in the picture below. Then, fix 3 screws.
Caution:
Don't untighten all of 3 screws at the same time or the whole metal plate would move right
and left. So, it is recommended to tight just 2 screws (center and right or center and left) and
adjust metal plate eight one side (right/left) after the other.
Before
After
Don’t touch the black
screw

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
