Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 244
Guideline for adjusting the adjustment dial
Moving to the rear side Moving to the front side
Adjust only when necessary
Supply
spool side adjustment dial
Winding spool side adjustment dial
3. Fix the adjustment dial fixing screws.
When the film moves to
the front side
When the film moves to
the rear side
When the film moves to
the rear side
When the film moves to
the front side
Basically, adjust only on the winding spool side. The supply side is
adjusted only when further adjustment is required or when the
supply side is skewed after printing.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
