Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 43
Error Code
Item
Description
1C-XX
Error Message
Invalid Film
Outline
Transfer film feed operation timeout error
Detection Description
The printer detected the feed operation timeout of the transfer film.
Remedy
[Related parts]
• Transfer Film Cassette
• Harnesses from the Film Beginning Sensor 1 (SN12
) to the Main board
• Harnesses from the Film Beginning Sensor 2 (SN13) to the Main board
• Film Beginning Sensor 1 (SN12)
• Film Beginning Sensor 2 (SN13)
• Main board
[Remedy]
1. Check the following items of the transfer film cassette.
⋅
There is no damage in the transfer film cassette.
⋅
There is no breakage or improper winding of the transfer film.
⋅
It is not empty.
⋅
The transfer film is properly set.
2. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
1D-01
Error Message
Invalid Film
1D-02
1D-03
Outline
Transfer film panel interval error (short)
Detection Description
The printer detected the panel interval error (short) of the transfer film.
Remedy
[Related parts]
• Transfer Film Cassette
• Harnesses from the Film Beginning Sensor 1 (SN12
) to the Main board
• Harnesses from the Film Beginning Sensor 2 (SN13) to the Main board
• Film Beginning Sensor 1 (SN12)
• Film Beginning Sensor 2 (SN13)
• Main board
[Remedy]
1. Check the following items of the transfer film cassette.
⋅
There is no damage in the transfer film cassette.
⋅
There is no breakage or improper winding of the transfer film.
⋅
It is not empty.
⋅
The transfer film is properly set.
2. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
1D-04
1D-05
1D-06
Error Message
Invalid Film
Outline
Transfer film panel interval error (long)
Detection Description
The printer detected the panel interval error (long) of the transfer film.
Remedy
[Related parts]
• Transfer Film Cassette
• Harnesses from the Film Beginning Sensor 1 (SN12
) to the Main board
• Harnesses from the Film Beginning Sensor 2 (SN13) to the Main board
• Film Beginning Sensor 1 (SN12)
• Film Beginning Sensor 2 (SN13)
• Main board
[Remedy]
1. Check the following items of the transfer film cassette.
⋅
There is no damage in the transfer film cassette.
⋅
There is no breakage or improper winding of the transfer film.
⋅
It is not empty.
⋅
The transfer film is properly set.
2. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
