Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 44
Error Code
Item
Description
1D-07
Error Message
Invalid Film
Outline
Transfer film empty redetection error
Detection
Description
After the printer detected the transfer film empty, it detected empty after
initialization again.
Remedy
[Related parts]
• Transfer Film Cassette
• Harnesses from the Film Beginning Sensor 1 (SN12
) to the Main board
• Harnesses from the Film Beginning Sensor 2 (SN13) to the Main board
• Film Beginning Sensor 1 (SN12)
• Film Beginning Sensor 2 (SN13)
• Main board
[Remedy]
1. Check the following items of the transfer film cassette.
⋅
There is no damage in the transfer film cassette.
⋅
There is no breakage or improper winding of the transfer film.
⋅
It is not empty.
⋅
The transfer film is properly set.
2. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
1D-08
Error Message
Invalid Film
Outline
Hologram film type error
Detection
Description
Remedy
[Related parts]
• Transfer Film Cassette
• Harnesses from the Film Beginning Sensor 1 (SN12
) to the Main board
• Harnesses from the Film Beginning Sensor 2 (SN13) to the Main board
• Film Beginning Sensor 1 (SN12)
• Film Beginning Sensor 2 (SN13)
• Main board
[Remedy]
4. Check the following items of the transfer film cassette.
⋅
There is no damage in the transfer film cassette.
⋅
There is no breakage or improper winding of the transfer film.
⋅
It is not empty.
⋅
The transfer film is properly set.
5. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
Check/replace the related harness/cable, connector and parts
1D-09
Error Message
Invalid Film
Outline
Abnormal index mark transfer position for hologram film
Detection
Description
Remedy
[Related parts]
• Transfer Film Cassette
• Harnesses from the Film Beginning Sensor 1 (SN12
) to the Main board
• Harnesses from the Film Beginning Sensor 2 (SN13) to the Main board
• Film Beginning Sensor 1 (SN12)
• Film Beginning Sensor 2 (SN13)
• Main board
[Remedy]
6. Check the following items of the transfer film cassette.
⋅
There is no damage in the transfer film cassette.
⋅
There is no breakage or improper winding of the transfer film.
⋅
It is not empty.
⋅
The transfer film is properly set.
7. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
Check/replace the related harness/cable, connector and parts

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
