Test Setup - Test Applications
84 FTBx-88000 Series
EtherSAM (Y.1564)
 Typical EtherSAM (Y.1564) test applications:
Network
under test
Testing Unit Loopback Unit
EXFO Unit EXFO Unit
Network
under test
Testing Unit Remote Unit
EXFO Unit EXFO Unit
Network
under test
Testing Unit
EXFO Unit
