Power Blazer 963
D Pop-Up
Add Channel (Multi-Channel OTN)
Channel ID is the channel ID to be added. Subsequent channel ID are
selected then assigned, skipping channel ID already assigned, when
adding more than one channel at once.
ODU Type is the ODU mapping type: ODU0, ODU1, ODU2, or ODU3. It
is possible to have different ODU types when the OTN-MIX-MAPPING
software option is enabled; otherwise all channels must have the same
ODU type.
Quantity is the number of channel to be added.
Bulk Read
Bulk Read button reads and displays the data based on the specified MDIO
range (MDIO/I2C Start Address to MDIO/I2C End Address).
Save to CSV button allows saving the read MDIO/I2C’s addresses and data
to a CSV file.
Note: The bulk read size is limited to 1024 addresses.
Bulk Write
Bulk Write allows configuring and writing MDIO/I2C data values for up to
20 addresses.
Page Select, available for I2C, allows selecting the I2C address page:
0x00 (default) to 0xFF.
Address and Data allows defining up to 20 MDIO/I2C addresses and
their data values: 0x0000 (default) to 0xFFFF for MDIO and 0x00
(default) to 0xFF for I2C.
