Test Configurator Overview
Test Configurator Overview
The Test Configurator tab displays the interconnected blocks composing
the test structure. Each block of the test structure gives an overview of its
configuration/status. Availability of each block depends on the selected test
application and its structure. Arrows are used to indicate the
interconnection between blocks as well as the direction of the clock and
data flow. Tap on a block or the More button for Intelligent Apps, to
change the configuration parameters of this block.
From the Test menu, tap Setup, and the Test Configurator tab.
Intelligent Apps:
iOptics:
Device Under Test block displays and allows changing the basic
interface/port settings. Tap on the More button to access more
information and settings.
Test Sequence block allows changing the basic test settings.
Test Sequence
Block
Device Under Test
Block
Connection
