150 FTBx-88000 Series
Modify Structure - DSn/PDH BERT
Modify Structure - DSn/PDH BERT
From the test menu, tap Setup, Test Configurator, and the Modify
Structure button.
Note: For Dual RX topology both RX and RX2 configurations are coupled.
 Interface/Rate allows the selection of the interface rate.
 Connector allows the selection of the physical port (see the
Interface/Rate table above).
 DSn Multiplexing / PDH Multiplexing allows the selection of the
DSn/PDH multiplexing.
 Client is set to Pattern.
Unit Interface/Rate Connector
8870
8880
DS1 [1.544 Mbit/s] Bantam
RJ48C
E1 [2.048 Mbit/s] Bantam
BNC
RJ48C
DS3 [44.736 Mbit/s]
E3 [34.368 Mbit/s]
E4 [139.264 Mbit/s]
BNC
Interface/Rate DSn/PDH Multiplexing
DS3 None (default), DS1, E1
DS1 None
E4 None (default), E3, E3/E2/E1
E3 None (default), E2/E1
E1 None
