Modify Structure - EtherBERT
Modify Structure - EtherBERT
From the test menu, tap Setup, Test Configurator, and the Modify
Structure button.
Note: For Dual Port topology each port is configurable individually.
Interface allows the selection of the interface rate. For Dual Port, both
ports must be either 10GE and less, 25GE, 50GE, or 40/100GE.
Unit Interface/Rate Connector
8870
8880
10GE LAN
10GE WAN
1GE Optical
100M Optical
Port 1 - SFP+
Port 2 - SFP+
10/100/1000M Electrical Port 1 - RJ45
Port 2 - SFP+ (RJ45)
a, b
88200NGE 100GE (4 Lanes) [103.125 Gbit/s] Port 1 - CFP4
Port 2 - QSFP (QSFP28)
100GE (2 Lanes) [106.25 Gbit/s]
100GE (1 Lane) [106.25 Gbit/s]
Port 2 - QSFP (QSFP28)
40GE (4 Lanes) [41.25 Gbit/s] Port 2 - QSFP (QSFP+)
10GE LAN
10GE WAN
1GE Optical
100M Optical
Port 1 - SFP+
10/100/1000M Electrical Port 1 - SFP+
a
