Setup
180 FTBx-88000 Series
Modify Structure - OTN-SONET/SDH BERT
Modify Structure - OTN-SONET/SDH BERT
From the test menu, tap Setup, Test Configurator, and the Modify
Structure button.
Note: The OTN-SONET/SDH BERT test is framed.
 Interface/Rate allows the selection of the interface rate.
 Connector allows the selection of the physical port (see the
Interface/Rate table above).
Unit Interface/Rate Connector
8870
8880
OTU2 [10.709 Gbit/s]
OTU1 [2.666 Gbit/s]
Port 1 - SFP+
88200NGE OTU4 (4 Lanes) [111.81 Gbit/s] Port 1 - CFP4
Port 2 - QSFP
a
a. This port accepts QSFP+ or QSFP28 transceivers.
OTU3 (4 Lanes) [43.018 Gbit/s] Port 2 - QSFP
a
OTU2 [10.709 Gbit/s]
OTU1 [2.666 Gbit/s]
Port 1 - SFP+
88260 OTU3 (4 Lanes) [43.018 Gbit/s] Port A1/A2/B1/B2 - QSFP28
OTU2 [10.709 Gbit/s]
OTU1 [2.666 Gbit/s]
Port A1/A2/B1/B2 - SFP28
