Setup
174 FTBx-88000 Series
Modify Structure - OTN BERT
Connector allows the selection of the physical port (see the
Interface/Rate table above).
Framing allows the selection of the test framing type for parallel
interfaces and is set to Framed for serial interfaces.
Framed (default): A single Pattern or Ethernet client applied
toward the physical lanes.
88460 OTU4 (4 Lanes) [111.81 Gbit/s]
OTU3e2 (4 Lanes) [44.583 Gbit/s]
OTU3e1 (4 Lanes) [44.571 Gbit/s]
OTU3 (4 Lanes) [43.018 Gbit/s]
OTU2f [11.318 Gbit/s]
OTU1f [11.270 Gbit/s]
OTU2e [11.096 Gbit/s]
OTU1e [11.049 Gbit/s]
OTU2 [10.709 Gbit/s]
OTU1 [2.666 Gbit/s]
Port 1/2/3/4 - QSFP28
a. This port accepts QSFP+ or QSFP28 transceivers.
Unit Interface/Rate Connector
