Graphical User Interface Overview
40 FTBx-88000 Series
Navigation Buttons
Navigation Buttons
Navigation buttons appear when there is not enough room on one page to
display all available test applications. The left and right arrow buttons allow
respectively accessing the previous or next window. The buttons in
between the left and right arrow buttons allow directly selecting the
window for the type of test application listed.
Status Bar
The status bar displays the following information.
Icon
and/or text
Description Test Application
Test icon Icon representing the active test application. All
P1, P2, P3, P4 Port identification number: Port x All
A1, A2, B1,
B2
Port identification number composed of the port of the FTBx-88260
module (A or B) and the transceiver system port (1 or 2)
All
[Lx] On 88260, indicates the Lane number when using a QSFP28 multilane
transceiver for a serial interface rate.
CPRI/OBSAI
eCPRI
TX/RX, TX, RX Indicates the direction of the signal per port. Transport,
Time Error /
Wander (DS1/E1)
Interface/
Signal
The interface or signal rate per port: 1GE Optical, 40G, OTU1,
OTU2, OTU3, etc.
All
(BTS) or
(RRH)
BTS: Emulation mode is Base Station
RRH: Emulation mode is Remote Radio Head
CPRI/OBSAI BERT
