Graphical User Interface Overview
Power Blazer 41
Status Bar
LINK For single or dual port, the status per port:
Green arrow: Link up.
Red arrow: Link down.
Gray arrow: Awaiting incoming data to provide a status.
All
CPRI/OBSAI BERT
For multiple link interface, the status of all enabled links:
Green arrow: Link up on all links.
Red arrow: Link down on at least one link.
Gray arrow: Awaiting incoming data to provide a status.
EtherBERT (Multiple
link interface)
For multiple Ethernet clients, the status of all enabled clients:
Green arrow: Link up on all clients.
Red arrow: Link down on at least one client.
Gray arrow: Awaiting incoming data to provide a status.
DCO (Multiple
Ethernet clients)
FlexO status
and size
Indicates the FlexO group status and its size:
Green arrow: FlexO Group Up.
Red arrow: FlexO Group Down.
FlexO BERT
PTP For G.8265.1 and G.8275.2:
Green arrow: Signaling requests granted.
Red arrow: Request denied, session canceled, or no reply.
Gray arrow: Pending, inactive, or link down.
For G.8275.1:
Green arrow: Announce, Sync, and Follow-up are received according
with their respective interval.
Red arrow: Announce, Sync, or Follow-up are not received.
Gray arrow: Pending.
Refer to Negotiation Status on page 212 for more information.
1588 PTP, Time Error /
Wander
ESMC Green arrow: ESMC valid information frame received.
Red arrow: No ESMC valid information frames received.
Gray arrow: Pending state.
Refer to ESMC Monitoring on page 432 for more information.
SyncE, Time Error /
Wander
Icon
and/or text
