Graphical User Interface Overview
42 FTBx-88000 Series
Status Bar
Power level The received optical signal status:
Green with “Power”: Power level in range
a
.
Yellow: Power level out-of-range
b
.
Red with “LOS”: Loss of signal
b
.
Red with “Power”: Power level is close to damage.
Gray: The power range information is either not available or not
supplied by the transceiver.
All except Cable Test
For multiple link interface, the power level status of all enabled link
using the following priority order:
1- Red with “Power”: Power level is close to damage on at least one
lane of any link.
2- Red with “LOS”: Loss of signal on at least one lane of any link.
3- Yellow: Power level out-of-range on at least one lane of any link.
4- Gray: The power range information is either not available or not
supplied by the transceiver for at least one lane of any link.
5- Green: Power level in range for all lanes on all link.
EtherBERT (Multiple
link interface)
Laser ON
b
. The laser icon is not displayed when the laser is off
a
. The
laser icon is only displayed for optical interfaces. The laser is ON by
default when the test is created. The laser control is not affected when
turning off the laser by generating a LOS for example. Refer to Laser
Button on page 769.
All
For multiple link interface, the laser status of all enabled link:
Laser ON for at least one lane of any link. The laser icon is not
displayed when the laser is off for all lanes on all links. The laser is ON
by default when the test is created. The laser control is not affected
when turning off the laser by generating a LOS for example. Refer to
Laser Button on page 769.
EtherBERT (Multiple
link interface)
Icon
and/or text
Description Test Application
