Test Results
570 FTBx-88000 Series
Summary - EtherSAM
Summary - EtherSAM
From the Test menu, tap Results, and the Summary tab.
Note: For Dual Test Set, only Start Time is displayed on the remote module.
Service Configuration/Performance Test indicates the actual test
status as follows:
Start Time indicates the date and time the test was started. The date
and time reset every time the test is restarted.
Remote unit in Dual Test Set Mode indicates that this unit is set as
remote but the DTS Connection is not established.
Test Status Description
“--” Test has not started.
Disabled Test/subtests is/are disabled.
Running Test/subtest is currently running.
Data Transfer Test/subtest is running but no test traffic is being transmitted.
Completed, <Verdict> Test/subtest has completed with the test pass/fail verdict. A
fail verdict is declared when a Link Down or LOS is detected,
or when any SLA parameter fails.
Aborted, <reason> Test/subtest has been aborted either manually (Stop) or
automatically from an alarm and the reason why the test has
been aborted is also displayed as follows:
Link down alarm, LOS alarm, Timeout during execution,
DTS connection failed, Loss of remote connection (DTS),
LOPPS-L Alarm
a
, LOPPS-R Alarm
a
,
LOPPS-L / LOPPS-R Alarm
a
, Unresolved addresses,
No test enabled, No L2CP Frame Enabled,
Invalid Burst Configuration, CIR disabled for all services,
Excessive Refill Time
b
, Stopped, NAT detection failed
a. Available for Dual Test Set in One-Way Latency measurement mode.
b. An excessive refill occurs when the pre-burst and/or post-burst duration last for
more than 2 seconds.
