Quantity allows selecting 2 to 8 frame size values.
EMIX Frame Sizes allows setting the EMIX frame sizes: 48
1
to 16000
2
.
The following table lists each component, when supported by the test
application, that may affect the minimum frame size value.
Restore Default button reverts the quantity and EMIX frame sizes to
their default values.
1. The minimum value is adjusted according to the frame structure and components selected as shown in the
following table. The minimum of 48 bytes is only available for rates up to 10GE, for higher rates the minimum frame
size is 64 bytes. For EtherSAM
the minimum frame size is 64 bytes.
2. The maximum frame size is limited to 10000 for 10/100/1000Mbps electrical interface.
Component Description
VLAN 4 bytes per VLAN
MPLS 4 bytes per label (up to two labels)
EoE Header 16 bytes
EoE VLAN 4 bytes
PBB-TE Header 18 bytes
B-VLAN 4 bytes
LLC and SNAP Headers 8 bytes
UDP 8 bytes
TCP 20 bytes
Ethernet Header 14 bytes
IPv4 20 bytes
IPv6 40 bytes
Latency 8 bytes
Using DTS 4 bytes
