Test Setup - Test Applications
64 FTBx-88000 Series
Multi-Channel OTN
Multi-Channel OTN
The Multi-Channel OTN test application validates individual channel
connectivity with a device under test by allowing concurrent generation
and monitoring of all channels of a single or mixed ODUmux test structure.
Typical Multi-Channel OTN test applications:
Path/Mapping
The Multi-Channel OTN test application offers the following
path/mapping structures depending on the inserted CFP4/QSFP
transceivers and enabled options. Mixed mapping is available with the
OTN-MIX-MAPPING software option.
Network
under test
Testing Unit DUT Loopback
EXFO Unit
Network
under test
Testing Unit Testing Unit
EXFO Unit EXFO Unit
