Filter Configuration
Filter Configuration
 “(“ and “)“, the open and close parenthesis controls the precedence of
operands when more than two operands are used. Only one level of
parenthesis is supported. When no parenthesis are used, a logical AND
has precedence over a logical OR.
 Not check box when selected, adds the logical negation (not equal)
operator for the operand filter defined at its right.
 Filter specifies the filter to be used (None by default).
 Value is the value associated to the selected filter.
Category Filter
Ethernet MAC Destination Address, MAC Source Address, EtherType
a
,
C-VLAN ID, S-VLAN ID, E-VLAN ID, C-VLAN Priority, S-VLAN Priority,
E-VLAN Priority, Frame Format
a. Applies only to the last EtherType occurrence when VLAN is used.
IPv4 IPv4 Destination Address, IPv4 Source Address, IPv4 TOS,
IPv4 Precedence, IPv4 Protocol, IPv4 DiffServ
IPv6 IPv6 Destination Address, IPv6 Source Address, IPv6 Flow Label,
IPv6 Next Header
b
, IPv6 Traffic Class, IPv6 Precedence, IPv6 DiffServ
b. Applies only to the last next header occurrence when extension headers are used.
Higher Layer TCP Destination Port
c
, TCP Source Port
c
, UDP Destination Port, UDP
Source Port
c. Available with 10M to 10G interface rates only.
MPLS
d
d. Available when the corresponding software option is enabled.
MPLS Label 1, MPLS Label 2, MPLS COS 1, MPLS COS 2
