Test Setup - Test Applications
Power Blazer 61
iOptics
iOptics
iOptics test application provides a quick assessment of the proper
operation of an optical transceiver before using it in a network or test
environment. The validation is done by running sub-tests in addition to
monitoring transceiver power consumption and temperature. Result and
verdict are reported for each sub-test and monitoring task. Transceiver’s
manufacturing information is also automatically collected.
Typical iOptics test applications:
For standard transceivers:
For bidirectional transceivers:
For an Active Optical Cable (AOC):
EXFO Unit
EXFO Unit
Same connector
type and rate
EXFO Unit
Two
QSFP
Ports
EXFO Unit
Single
QSFP
Port
EXFO Unit
