Physical Interfaces and LEDs
Power Blazer 23
FTBx-88260 and Transceiver Systems
FTBx-88260 and Transceiver Systems
Note: The FTBx-88260 module with TA-SFP28 transceiver systems are shown
below as examples for connector location purposes.
 TA-SFP28
 TA-QSFP28
1. Laser radiation is emitted from this port when LASER LED is on.
Port A Port B FTBx-88260
Port A1
1
TA-SFP28 Port A2
1
Port B1
1
Port B2
1
1. Laser radiation is emitted from this
port when LASER LED is on.
Port 1
1
: SFP28 Port 2
1
: SFP28
Port 1
1
: QSFP28 Port 2
1
: QSFP28
1. Laser radiation is emitted from this
port when LASER LED is on.
