Physical Interfaces and LEDs
22 FTBx-88000 Series
FTBx-88200NGE
QSFP Optical IN/OUT port QSFP+
transceiver
b
Ethernet 40 Gbit/s
OTU3e2, OTU3e1, OTU3
Optical IN/OUT port QSFP28
transceiver
a
Ethernet 100 Gbit/s
OTU4
Optical IN/OUT port QSFP56
transceiver
c
Ethernet 100 Gbit/s
REF OUT Electrical port SMA for eye
diagram clock signal
generation
EXT CLK Electrical port SMB for
external clock synchronization
DS1/1.5M, E1/2M, 2MHz, 1PPS
d
a. Only OTU4 (4 Lanes) and 100GE (4 Lanes) are supported.
b. Only parallel interfaces are supported.
c. Only 100GE (4 Lanes) is supported.
d. Available for Dual Test Set - One-Way Latency measurement mode.
Port
Labelled
Description Supported Signal(s)
