Physical Interfaces and LEDs
34 FTBx-88000 Series
FTBx-8870/8880
FTBx-8870/8880
The following table shows the list of available ports as well as a description
and the signals supported for each module.
Connector Labelled Description and supported signal(s)
Module
8870 8880
Bantam BANTAM
TX/RX2
RX
TX and RX: DS1/1.5M, E1/2M
RX2: DS1/1.5M
- X
Clock IN/OUT: DS1/1.5M, E1/2M, 2 MHz
SFP+
1
P2
1. Laser radiation is emitted from this port when LASER LED is on.
SFP+
1
P1
RJ45
P1
RJ48C BANTAM BNC
TX/RX2
BNC
RX
DUPLEX
LINK/ACT
LINK/RX
LASER
BNC
EXT CLK
