Physical Interfaces and LEDs
Power Blazer 33
FTBx-88480, FTBx-88481, FTBx-88482, and Transceiver Systems
The following table shows the list of available ports and the supported
signals on each module excluding the TA transceiver system ports.
The following table shows the list of available transceiver systems and the
supported signals.
Port
Labelled
Description Supported Signal(s) Module
QSFP-DD 1
QSFP-DD 2
Optical IN/OUT port
QSFP-DD transceiver
400 Gbit/s Ethernet
400ZR (CFEC, 16QAM, DWDM Amplified)
400ZR (CFEC, 16QAM, Unamplified)
400ZR+ (OFEC, 16QAM)
88480
88481
88482
Optical IN/OUT port QSFP56
transceiver
200 Gbit/s Ethernet
OSFP Optical IN/OUT port
OSFP transceiver
400 Gbit/s Ethernet 88481
88482
SFP-DD Optical IN/OUT port
SFP56 transceiver
Fibre Channel 64X 88480
REF OUT Electrical port SMA for eye
diagram clock signal generation
88480
88481
88482
Transceiver
System
Port
Labelled
a
a. The ports are listed/referred as follows in the GUI: Port, A, transceiver system port (1 or 2), and connector
type; for example Port A1 - QSFP28.
Description Supported Signal(s)
TA-QSFP28
(two ports)
1
2
Optical IN/OUT port
QSFP28 transceiver
Ethernet 100 Gbit/s
Optical IN/OUT port
QSFP56 transceiver
Ethernet 100 Gbit/s
