Test Setup - Test Applications
100 FTBx-88000 Series
1588 PTP
1588 PTP
The 1588 PTP (Precision Time Protocol) test application handles the
1588 PTP communication with the Grand Master (GM) clock and/or
Boundary clock (BC), collects statistics related to packets, and monitors
the clock Quality Level.
Typical 1588 PTP test application:
Network
under test
Testing Unit GM Clock
EXFO Unit Grand Master Clock Source
Network
under test
GM Clock
Grand Master Clock SourceEXFO Unit Boundary Clock
BCTesting Unit
