Modify Structure - RFC 2544
Modify Structure - RFC 2544
From the test menu, tap Setup, Test Configurator, and the Modify
Structure button.
Note: For Dual Port topology each port is configurable individually.
 Interface/Rate allows the selection of the interface rate.
Unit Interface/Rate Connector
8870
8880
10GE LAN,
10GE WAN
1GE Optical
100M Optical
Port 1 - SFP+
Port 2 - SFP+
10/100/1000M Electrical Port 1 - RJ45
Port 2 - SFP+ (RJ45)
a, b
88200NGE 100GE (4 Lanes) [103.125 Gbit/s] Port 1 - CFP4
Port 2 - QSFP (QSFP28)
100GE (2 Lanes) [106.25 Gbit/s]
100GE (1 Lane) [106.25 Gbit/s]
Port 2 - QSFP (QSFP28)
40GE (4 Lanes) [41.25 Gbit/s] Port 2 - QSFP (QSFP+)
10GE LAN
10GE WAN
1GE Optical
100M Optical
Port 1 - SFP+
10/100/1000M Electrical Port 1 - SFP+
a
