Setup
Power Blazer 423
Streams - Global
Streams - Global
From the Test menu, tap Setup, Test Configurator, the protocol block, and
the Global tab.
The following parameters are displayed and configurable per stream.
Check boxes:
The first check box (top-left) allows enabling stream(s) sequentially
within the limit of the link capacity.
The check boxes next to the stream numbers allow enabling each
stream individually within the limit of the link capacity.
Stream Name
1
indicates the name of each stream. Tap on the Stream
Name button to modify the name of each stream.
Frame Size
1
indicates the frame size of each stream. Tap on the Frame
Size button to modify the frame size of each stream.
TX Rate
1
indicates the transmission rate for each stream. Tap on the
TX Rate button to modify the transmission rate (see page 428).
Framing indicates the framing of each service. Tap on the Framing
button to modify the Frame Format, Network Layer, Transport Layer,
VLAN, and MPLS when applicable (see Modify Frame Structure from
the MAC/IP/UDP on page 330).
VLAN indicates the ID and Priority of each VLAN level for each stream.
Tap on the VLAN button to modify the VLAN settings (see VLAN from
the MAC/IP/UDP tab).
Addressing MAC/IP indicates the source and destination MAC/IP
addresses for each stream. Tap on the Addressing MAC/IP button to
modify the customer addressing (see MAC and IP from the
MAC/IP/UDP tab). When using Provider Encapsulation, the source
and destination addresses displayed are respectively EoE MAC for EoE
and B-MAC for PBB-TE.
1. See the Profile tab for more information.
