Setup
422 FTBx-88000 Series
Smart Loopback
UDP/TCP (default), for Ethernet Layer 4, swaps the UDP or TCP
ports and the MAC and IP addresses of received packets having
their Destination IP address matching the IP address of the
loopback port. For Ethernet Layer 3, swaps the MAC and IP
addresses for packets having their Destination IP address
matching the IP address of the loopback port. For Ethernet Layer 2,
swaps the MAC addresses for packets having their Destination
MAC address matching the MAC address of the loopback port.
Matching & Swapping indicates the Loopback parameters that will be
used based on the Loopback Mode selected.
S-OAM Responder
The S-OAM Responder check box when selected (default) allows
responding to LBM, LTM, DMM, LMM, and SLM valid messages (test
running or not). Traffic statistics are also monitored (refer to Responder on
page 648).
Respond to... message Respond with... message
LBM LBR
LTM LTR
DMM DMR
LMM LMR
SLM SLR
