Traces - SONET/SDH
Traces - SONET/SDH
For SONET/SDH BERT and SONET/SDH - DSn/PDH BERT: From the test
menu, tap Setup, Test Configurator, the interface block, and on the
Traces tab.
For OTN-SONET/SDH BERT: From the test menu, tap Setup, Test
Configurator, the protocol block, and on the Traces tab.
Traces
Note: Selecting a Trace byte to be generated will automatically update the
corresponding OH byte. Refer to OH - SONET/SDH on page 710 for more
information. Configuration is coupled with settings from Traces -
SONET/SDH on page 634.
 Section (J0) / RS (J0), STS Path (J1) / AU Path (J1) / TU-3 Path (J1),
VT Path (J2) / TU Path (J2)
Format allows the selections of the J0/J1/J2 format: 1 Byte (default),
16 Bytes, or 64 Bytes.
Generated, available when the 16 bytes or 64 bytes format is selected,
allows entering the J0/J1/J2 trace value/message to be generated.
Format
(bytes)
Default Traces J0/J1/J2
1 01
a
a. Hexadecimal value. Refer to OH - SONET/SDH on page 710 to change this value.
J0/J1/J2
16 EXFO SONET/SDH J0/J1/J2
64 EXFO SONET/SDH Analyzer Section/RS trace test message J0
EXFO SONET/SDH Analyzer high order path trace test message J1 (STS/AU)
EXFO SONET/SDH Analyzer low order path trace test message J1 (TU-3)/J2
