Test Functions
730 FTBx-88000 Series
Path OAM APS
Path OAM APS
Note: Available when Path OAM is enabled, refer to Path OAM on page 359.
From the test menu, tap Functions and the Path OAM APS tab.
Path OAM APS check box when selected (cleared by default) enables
the generation and monitoring of APS messages when the test is
running.
Request/State Interpretation allows selecting the standard used for
request/state interpretation: G.873.1 (default) or G8331.
Path OAM on Client ID indicates on which client ID the path OAM
applies.
TX/RX
Request/State: Bits 1 to 4 of the APS data byte 0. Reserved
request/state values are not available for transmission.
Bits 1 to 4
Request/State
G.873.1 G8331
1111 Lockout of protection (LoP) Lockout of protection (LO)
1110 Forced switch (FS) Signal Fail on Protection (SF-P)
1101 Reserved Forced Switch (FS)
1100 Signal fail (SF) Reserved
1011 Reserved Signal Fail on Working (SF-W)
1010 Signal degrade (SD) Reserved
1001 Reserved Signal Degrade (SD)
1000 Manual switch (MS) Reserved
0111 Reserved Manual Switch (MS)
0110 Wait-to-restore (WTR) Reserved
0101 Reserved Wait-to-Restore (WTR)
