Test Functions
Power Blazer 731
Path OAM APS
 Requested Signal: Bits 1 to 8 of the APS data byte 1: 0 Null Signal
(Default), 1, 2, ..., 254, 255 Extra Traffic Signal.
 Bridged Signal: Bits 1 to 8 of the APS data byte 2: 0 Null Signal
(Default), 1, 2, ..., 254, 255 Extra Traffic Signal.
 Reserved: Bits 1 to 8 of the APS data byte 3: 0 (default) to 255.
 Protection Type: Bits 5 to 8 of the APS data byte 0.
0100 Exercise (EXER) Exercise (EXER)
0011 Reserved Reserved
0010 Reverse request (RR) Reverse Request (RR)
0001 Do not revert (DNR) Do Not Revert (DNR)
0000 No request (NR) (Default) No Request (NR) (Default)
Protection Type
Bit
Description
# Value
A 5 0 No APS Channel (Default)
1 APS Channel
B 6 0 1+1 (permanent bridge) (Default)
1 1:n (no permanent bridge)
D 7 0 Unidirectional switching (Default)
1 Bidirectional switching
R 8 0 Non-revertive operation (Default)
1 Revertive operation
Bits 1 to 4
Request/State
G.873.1 G8331
