Setup
212 FTBx-88000 Series
1588 PTP (Client)
IP TOS/DS (IPv4) allows entering the Type of Service (TOS) or
Differentiated Services (DS): 0x00 (default) to 0xFF. Only available
with Unicast mode.
Traffic Class (TOS/DS) (IPv6) allows entering the Type of Service
(TOS) or Differentiated Services (DS): 0x00 (default) to 0xFF. Only
available with Unicast mode.
TOS/DS Config: Refer to TOS/DS Config on page 1016.
Mechanism is not selectable and is set to Delay Req-Resp (Delay
Request-Response) which specifies the mechanism used by the
1588 PTP function to communicate with the Grand Master clock. Refer
to Delay Request-Response on page 829 for more information.
Delay Mode is not selectable and is set to Two-way which uses
Sync/Follow Up, Delay Request, and Delay Response messages.
Connect button is used to initiate the Grand Master Connection
process. This process is also automatically initiated when starting the
test if not already initiated. The process automatically ends when
stopping the test. Only available with Unicast mode.
Negotiation Status is displayed during the Unicast negotiation process
which is initiated when either the test is started or the Connect button
is activated. Only available with Unicast mode.
Negotiation
Status
Description
Background
Color
a
Request Granted All the Signaling request types have been granted. Green
[Message type]
Request Denied
The Signaling grant message has not been granted. Red
Session Canceled The Grand Master has canceled the Unicast session. Red
