Setup
Power Blazer 213
1588 PTP (Client)
 GM Info / BC Info: Refer to Grand Master Information / Boundary
Clock Information on page 975.
 Message Rate
 Announce determines the transmission interval of the Announce
messages:
G.8265.1: 1 msg/16s, 1 msg/8s, 1 msg/4s, 1 msg/2s (default),
1 msg/s, 2 msg/s, 4 msg/s, or 8 msg/s.
G.8275.1, indicates the announce rate log message interval.
G.8275.2: 1 msg/s (default), 2 msg/s, 4 msg/s, or 8 msg/s.
 Sync determines the transmission interval of the Sync messages:
G.8265.1: 1 msg/16s, 1 msg/8s, 1 msg/4s, 1 msg/2s, 1 msg/s,
2 msg/s, 4 msg/s, 8 msg/s, 16 msg/s, 32 msg/s (default), 64 msg/s,
or 128 msg/s
G.8275.1, indicates the sync rate log message interval.
G.8275.2: 1 msg/s, 2 msg/s, 4 msg/s, or 8 msg/s, 16 msg/s,
32 msg/s (default), 64 msg/s, or 128 msg/s
No Reply No message is received from the Grand Master following
transmission of 3 Signaling requests for a message type.
Make sure that both IP address and Domain (refer to 1588 PTP
(Client) on page 210) of the Grand Master Clock are valid as well as
the IP address of the unit’s port used to connect on the network
(refer to Network on page 343).
Red
Pending Unicast negotiation has started and no message has been received
from the Grand Master.
Gray
Inactive The Unicast negotiation is not active. Gray
a. The gray background color is also used for a Link Down.
Negotiation
Status
Description
Background
Color
a
