Setup
Power Blazer 205
Modify Structure - Time Error / Wander
Wander
PHY Type allows selecting the transceiver PHY type:
For 100GE (4 Lanes): LR4/ER4 (default), SR4, CWDM4, or CLR4. The
PHY type when set to any except LR4/ER4, provides access to RS-FEC
configuration (see page 305).
Connector allows the selection of the physical port (see the
Interface/Rate table above).
Unit Interface/Rate Connector
8880 10GE LAN
1GE Optical
100M Optical
Port 1 - SFP+
10/100/1000M Electrical Port 1 - RJ45
10 MHz
2 MHz
BNC (Port labelled TX/RX2)
RJ48C
DS1 [1.544 Mbit/s] Port 1 - Bantam
Port 1 - RJ48C
E1 [2.048 Mbit/s] Port 1 - Bantam
Port 1 - BNC
Port 1 - RJ48C
88260 100GE (4 Lanes) [103.125 Gbit/s] Port A1/A2/B1/B2 - QSFP28
25GE
10GE LAN
1GE Optical
100M Optical
Port A1/A2/B1/B2 - SFP28
10 MHz
2 MHz
Port A1/B1 - EXT-CLK
