Setup
326 FTBx-88000 Series
Local Details - iSAM
 Connector allows the selection of the physical port (see the
Interface/Rate table above).
 PHY Type allows selecting the transceiver PHY type:
For 100GE (4 Lanes): LR4/ER4 (default), SR4, CWDM4, CLR4, AOC, or
Other. The PHY type when set to any except LR4/ER4, provides access
to RS-FEC configuration (see page 305).
For 100GE (1 Lane): DR1/FR1/LR1 (default and dimmed); ensure the
other end of the circuit has the FEC enabled.
For 100GE (2 Lanes): SRBD (default and dimmed); ensure the other
end of the circuit has the FEC enabled.
88200NGE 100GE (4 Lanes) [103.125 Gbit/s] Port 1 - CFP4
Port 2 - QSFP (QSFP28)
100GE (2 Lanes) [106.25 Gbit/s]
100GE (1 Lane) [106.25 Gbit/s]
Port 2 - QSFP
40GE (4 Lanes) [41.25 Gbit/s] Port 2 - QSFP (QSFP+)
10GE LAN
1GE Optical
100M Optical
Port 1 - SFP+
10/100/1000M Electrical Port 1 - SFP+ (RJ45)
a
88260 100GE (4 Lanes) [103.125 Gbit/s] Port A1/A2/B1/B2 - QSFP28
Port A1/B1 - CFP4
100GE (2 Lanes) [106.25 Gbit/s]
100GE (1 Lane) [106.25 Gbit/s]
Port A1/A2/B1/B2 - QSFP28
40GE (4 Lanes) [41.25 Gbit/s] Port A1/A2/B1/B2 - QSFP28
10GE LAN
1GE Optical
100M Optical
Port A1/A2/B1/B2 - SFP28
10/100/1000M Electrical Port A1/A2/B1/B2 - SFP28 (RJ45)
a
a. Ethernet 10/100/1000M electrical is supported when using an active copper SFP.
Unit Interface/Rate Connector
