Setup
344 FTBx-88000 Series
Network
IP
IP Version allows selecting IPv4 (default) or IPv6
1
. IP Version is
coupled for all links with multiple link interface.
For IPv4 only:
Automatic IP (DHCP) check box when selected (cleared by default)
allows obtaining an IP address dynamically from a DHCP (Dynamic
Host Configuration Protocol) server.
Note: IP Address, Subnet Mask, and Default Gateway are not configurable
when the Automatic IP (DHCP) check box is selected.
IP Address allows entering the IP address of the port. The default
address is 10.10.x.y, where x and y are respectively the two least
significant bytes of the port default MAC address.
Subnet Mask allows entering the Subnet Mask (default is 255.255.0.0).
Default Gateway check box when selected (cleared by default) allows
entering a default Gateway IP address (default is 0.0.0.0).
For IPv6 only; refer to IPv6 Address Configuration on page 977 (Config...
button) for Link-Local IPv6 Address, Global IPv6 Address, Default
Gateway, and for additional settings.
1. Not supported with: 50G, 100G on 88460 (RFC 2544 and Smart Loopback), eCPRI, TCP Throughput. For 25G, only
supported with Traffic Gen & Mon.
