Test Results
Power Blazer 633
Traces - OTN
Operator Specific indicates the received Operator Specific message
(TTI bytes 32 to 63).
SAPI OTU-TIM / SAPI ODU-TIM / SAPI TCM-TIM check box, when
selected (cleared by default), allows editing the expected Source
Access Point Identifier and also enables OTU/ODU/TCM-TIM alarm
monitoring. For Multi-Channel OTN lower ODU layer, these check
boxes are only available from the test setup.
DAPI OTU-TIM / DAPI ODU-TIM / DAPI TCM-TIM check box, when
selected (cleared by default), allows editing the expected Destination
Access Point Identifier and also enables the OTU/ODU-TIM alarm
monitoring. For Multi-Channel OTN lower ODU layer, these check
boxes are only available from the test setup.
Copy RX / Global Copy RX
1
allows using the received SAPI/DAPI
message as the expected one. For Multi-Channel OTN lower ODU layer,
use the arrow button next to the Copy RX or Global Copy RX to switch
from one button to the other. Global Copy RX allows using the current
channel received SAPI/DAPI message as the expected one for all
channels while Copy RX only affects the selected channel.
1. Only available for the lower ODU layer for Multi-Channel OTN and FlexO BERT.
