Test Control
776 FTBx-88000 Series
Lpbk Tool Button (Loopback Tool)
Automatic mode is selected when the Auto-Negotiation check box is
selected and allows detecting automatically the MDI or MDIX cable
type.
Local Clock is only available with 1GE electrical interface and allows
setting the provenance of the clock: Master (default), or Slave, or
Auto
1
.
Network tab
Refer to Network on page 343 for more information.
SFP/SFP+ tab
Refer to CFP/OSFP/QSFP/SFP on page 242 for more information.
1.
Auto
is only available when the
Auto-Negotiation
check box is selected.
