Power Blazer 961
Errors
 Symbol for Ethernet 100/1000 Mbit/s interface and EoOTN 1GbE client,
indicates that an invalid code-group is detected in the code.
 Symbol for Fibre Channel 1X/2X/4X/8X, indicates that invalid
code-group is detected in the code.
 Sync Header for CPRI 10.1G and 24.3G (RS-FEC disabled), indicates
sync header violations.
 TC-IEC-P / HPTC-IEC (Incoming Error Count) for SONET/SDH with TCM
enabled, indicates the number of B3 parity violations detected at the
TC Source for STS-1 SPE/VC-3 and above (bits 1 to 4 of the N1 byte).
 TC-OEI-P / TC-OEI-V / HPTC-OEI / LPTC-OEI (Outgoing Error
Indication) for SONET/SDH with TCM enabled, indicates errored blocks
of the outgoing VTn/VC-n (bit 6 of the N1 or Z6/N2 byte). In TX, bit 6 of
the N1 or Z6/N2 byte is set to 1.
 TC-REI-P / TC-REI-V / HPTC-REI / LPTC-REI (Remote Error Indication)
for SONET/SDH with TCM enabled, indicates errored blocks caused
within the Tandem Connection (bit 5 of the N1 or Z6/N2 byte). In TX, bit
5 of N1 or Z6/N2 byte is set to 1.
Number of
BIP-8 violations
Bit
Number of
BIP-8 violations
Bit
1 2 3 4 1 2 3 4
0 0 0 0 0 8 1 0 0 0
1 0 0 0 1 0 1 0 0 1
2 0 0 1 0 0 1 0 1 0
3 0 0 1 1 0 1 0 1 1
4 0 1 0 0 0 1 1 0 0
5 0 1 0 1 0 1 1 0 1
6 0 1 1 0 0 (IAIS) 1 1 1 0
7 0 1 1 1 0 1 1 1 1
