CHAPTER 12
PAGE 5
PAGE DATE: 7. July 2010
MAINTENANCE MANUAL EXTRA 300LT
REPLENISHING
I M P O R T A N T Under no circumstances should fuel of lower octane rat-
ing or automotive fuel (regardless of octane rating) be
used. It is recommended that personnel be familiar
with Service Instruction No.1070 regarding specified
fuel for Lycoming engines.
Fuel System Capacities
Wing tank LH 76 L (20.1 US Gallons)
Wing tank RH 76 L (20.1 US Gallons)
Center tank 60 L (15.9 US Gallons)
Acro tank 9 L (2.3 US Gallons)
Total fuel capacity 221 L (58.4 US Gallons)
Usable fuel capacity 209 L (55.2 US Gallons)
Usable fuel capacity
for acrobatic 67 L (17.7 US Gallon)
I M P O R T A N T For acrobatic flight wing tanks must be empty.
I M P O R T A N T After refueling, it has to be ensured that both fuel tank
caps are securely installed prior to flight.
Additionally one has to wait at least five minutes for mois-
ture and sediment to settle before draining and checking the
fuel drain valves.
Refueling
